KOLOMNA 1563 CNC

KOLOMNA 1563 CNC
Verified seller
Price on request
Make an offer
Manufacturer
KOLOMNA
Model
1563 CNC
Year
Location
Italy
Category
Lathes - CNC vertical turret lathes
Product id
P251125192
Buy this machine
Language
Language
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
KOLOMNA 1563 CNC
Get price & details
+39 3 93…
Show phone
Details
About this seller
Specifications
Plate diameter
6300 mm
Working height
4000 mm
CNC type
ECS 2801
Max piece weight
125000 kg
Overhauled
yes
Year of overhauling
2007
-------------------
Length x width x height
8213.0
× 14200.0
× 9765.0
Weight
223000 kg
worked hours
hours under power
state
as-is, where-is
At local norms
---------
status
Last availability date
17/03/2026
Show more
Automatic description (AI-Generated)
The KOLOMNA 1563 CNC is a large vertical turret lathe designed for heavy-duty machining tasks. It features a robust table with a diameter of 6,300 mm, capable of accommodating workpieces up to 6,300 mm in diameter and 4,000 mm in height. The machine supports a maximum workpiece weight of 125,000 kg, making it suitable for processing very large and heavy components.
This lathe is equipped with the ECS 2801 numerical control system, which includes a control panel featuring a screen, keyboard, and multiple buttons and rotary switches for precise operation. The control panel shows signs of use but appears intact and functional.
The machine offers significant travel capabilities, including a maximum vertical travel of the crosshead of 3,000 mm and horizontal travel of the tool head up to 3,575 mm. The tool head can tilt between -15° and +30°, allowing for versatile machining angles. Rapid traverse speeds reach up to 2,400 mm/min for both horizontal and vertical movements, with a traverse travel speed of 300 mm/min. The table speed is continuously variable, powered by an installed motor with 220 HP (161 kW).
Overall dimensions of the machine are substantial, measuring 8,213 mm in length, 14,200 mm in width, and 9,765 mm in height, with a total weight of 223,000 kg. The machine was overhauled in 2007.
Included with the lathe are several accessories: a copying device, conical turning device, bevel turning gear set, gear set for threading, and a telescopic platform. The machine is situated within an industrial workshop environment and is equipped with a yellow safety cage/platform and safety railings to ensure operator safety. Visual inspection shows a large cylindrical metal workpiece currently mounted on the lathe table, with metal shavings and tools nearby, indicating recent machining activity. Two workers in blue uniforms and helmets are seen operating or inspecting the machine, suggesting active use within a well-lit and maintained facility.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Show more
Seller's description
KOLOMNA VERTICAL TURNWHEEL mod. 1563
ECS 2801 numerical control
Table diameter mm 6,300
Maximum workpiece diameter mm 6,300
Maximum workpiece height mm 4,000
Distance from the table to the lower edge of the crosshead mm 3690 - 690
Maximum allowable weight kg 125,000
Maximum vertical travel of the crosshead mm 3,000
Maximum horizontal travel of tool head mm 3,575
Maximum vertical travel of tool head mm 2,000
Tool head tilt angles - 15° / + 30°
Horizontal travel of the tool head from the center of the table mm 3,425
Horizontal travel of the tool-holding head beyond the center of the table mm 150
Rapid horizontal and vertical speed mm/min 2,400
Traverse travel speed mm/min 300
Table speed continuously variable
Installed power HP 220 (161 Kw)
Machine weight Kg 223,000
Overall dimensions in plan mm 8,213 x 14,200
Overall dimensions in height from floor mm 8,315
Overall height dimensions mm 9,765
Complete with:
- Copying device
- Conical turning device
- Bevel turning gear set
- Gear set for threading
- Telescopic platform
USED MACHINE OVERHAULED 2007
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
