EMAG VSC 200 TWIN OP 50 CNC vertical turret lathe

EMAG VSC 200 TWIN OP 50 CNC vertical turret lathe
Top seller
Price on request
View price
Manufacturer
EMAG
Model
VSC 200 TWIN OP 50
Year
2005
Location
Switzerland
Category
Lathes - CNC vertical turret lathes
Product id
P260527184
Buy this machine
Language
Language
CNC каруселен струг EMAG VSC 200 TWIN OP 50
CNC svislý karuselový soustruh EMAG VSC 200 TWIN OP 50
EMAG VSC 200 TWIN OP 50 CNC-karusseldrejebænk
EMAG VSC 200 TWIN OP 50 CNC-Karusselldrehmaschine
Κάθετος τόρνος CNC EMAG VSC 200 TWIN OP 50
EMAG VSC 200 TWIN OP 50 CNC vertical turret lathe
Torno vertical CNC EMAG VSC 200 TWIN OP 50
Tour vertical CNC EMAG VSC 200 TWIN OP 50
CNC karuselni tokarski stroj EMAG VSC 200 TWIN OP 50
EMAG VSC 200 TWIN OP 50 CNC karusszel esztergagép
Tornio verticale CNC EMAG VSC 200 TWIN OP 50
EMAG VSC 200 TWIN OP 50 CNC karuselinės tekinimo staklės
EMAG VSC 200 TWIN OP 50 CNC-carrouseldraaibank
Tokarka karuzelowa CNC EMAG VSC 200 TWIN OP 50
Torno vertical CNC EMAG VSC 200 TWIN OP 50
Strung carusel CNC EMAG VSC 200 TWIN OP 50
EMAG VSC 200 TWIN OP 50 Карусельный токарный станок с ЧПУ
CNC karuselni strug EMAG VSC 200 TWIN OP 50
EMAG VSC 200 TWIN OP 50 CNC-karusellsvarv
CNC dikey torna EMAG VSC 200 TWIN OP 50
Get price & details
+34 679 …
Show phone
Details
About this seller
Specifications
CNC type
Overhauled
no
-------------------
Weight
12000 kg
worked hours
hours under power
state
as-is, where-is
At local norms
---------
status
Datasheet
Emag VSC 200 TWIN OP 50
Last availability date
28/05/2026
Show more
Automatic description (AI-Generated)
This EMAG VSC 200 TWIN OP 50 is a 4-axis vertical turning machine designed for medium to large series production. Manufactured in 2005, it is equipped with two spindles that enable simultaneous machining of two workpieces, enhancing productivity. The machine features independent X and Z axis drives, allowing precise and flexible operation, supported by independent measuring systems for accuracy.
The machine accommodates a maximum chuck diameter of up to 250 mm and offers a swing diameter of 260 mm. It provides a substantial X-axis travel of 850 mm and a Z-axis travel of 200 mm, suitable for a variety of turning tasks. Rapid traverse speeds reach 45 m/min on the X axis and 30 m/min on the Z axis, facilitating efficient machining cycles.
Powered by asynchronous motors, the spindles deliver 39 kW at a 40% duty cycle and 28 kW at 100% duty cycle, with a maximum spindle speed of 6000 RPM. Torque values are 460 Nm (40% duty cycle) and 340 Nm (100% duty cycle), with full power available from 800 rpm. The machine employs a disc turret with 2 × 8 tool stations, compatible with DIN 69 880 tool holders and 40 mm tool shanks, enabling versatile tooling options.
Additional features include an automatic pick-up loading system with conveyor-based automation for workpiece handling and vertical workpiece clamping. The machine bed is constructed from polymer concrete MINERALIT® for stability. Electrical specifications include a 400 V operating voltage, 66 kW connected load, and compliance with VDE 0113 standards. Available control systems include FANUC 31i/32i, Siemens SINUMERIK 840 D, and Bosch Rexroth MTX.
With a machine weight of approximately 12,000 kg and 16 total tool positions, this EMAG VSC 200 TWIN OP 50 offers robust capabilities for high-quality turning applications. Please note that specifications may vary slightly as these machines are custom-made. Contact us for further information and detailed technical support.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Show more
Seller's description
This 4-axis EMAG VSC 200 TWIN OP 50 was manufactured in 2005. It features simultaneous machining of two workpieces, independent X and Z axis drives, and a maximum chuck diameter of 250 mm. With a maximum X travel of 850 mm and a rapid traverse speed of 45 m/min, this machine is designed for medium to large series production. If you are looking to get high-quality turning capabilities, consider the EMAG VSC 200 TWIN OP 50 vertical turning machine we have for sale. Contact us for further details.Operation Types: OP 50
Machine Type: EMAG VSC 200 TWIN
Production Type: Medium to Large Series Production
Number of Spindles: 2
Simultaneous Machining of Two Workpieces: Yes
Independent X and Z Axis Drives: Yes
Independent Measuring Systems: Yes
Driven Tools: Yes
Maximum Chuck Diameter: 200 / 250 mm
Swing Diameter: 260 mm
Loading Time: 2–4 s
Spindle Flange: DIN 55 026 Size 6
Front Spindle Bearing Diameter: 100 mm
Main Drive Type: Asynchronous Motor
Spindle Power (40% Duty Cycle): 39 kW
Spindle Power (100% Duty Cycle): 28 kW
Torque (40% Duty Cycle): 460 Nm
Torque (100% Duty Cycle): 340 Nm
Full Power Available From: 800 rpm
Rapid Traverse X Axis: 45 m/min
Rapid Traverse Z Axis: 30 m/min
Feed Force X/Z: 11 kN
Ball Screw Diameter X/Z: 50 / 40 mm
Turret Type: Disc Turret
Tool Stations: 2 × 8
Tool Holder Standard: DIN 69 880
Tool Shank Diameter: 40 mm
Turret Index Time: 0.3 s
Machine Bed Material: Polymer Concrete MINERALIT®
Automatic Pick-up Loading System: Yes
Automatic Workpiece Loading and Unloading: Yes
Vertical Workpiece Clamping: Yes
Operating Voltage: 400 V
Control Voltage DC: 24 V
Control Voltage AC: 230 V
Frequency: 50 Hz
Connected Load: 66 kW
Fuse Protection: 160 A
Electrical Standard: VDE 0113
Available Control Systems: FANUC 31i / 32i, Siemens SINUMERIK 840 D, Bosch Rexroth MTX
Workpiece Handling: Conveyor-Based Pick-up Automation
The technical specifications may vary slightly, as these are custom-made machines!
Driven Tools: yes
Machine Weight: 12000 kg
Number of Axes: 4
Number of Tools: 16
Spindle Power: 39 kW
Spindle Speed: 6000 RPM
X-axis Travel: 850 mm
Z-axis Travel: 200 mm
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
