EMAG VSC 250 vertical turret lathe with cnc

EMAG VSC 250 vertical turret lathe with cnc
Top seller
Price on request
Make an offer
Manufacturer
EMAG
Model
VSC 250
Year
2011
Location
Germany
Category
Lathes - CNC vertical turret lathes
Product id
P241001222
Buy this machine
Language
Language
вертикален револверен струг с ЦПУ EMAG VSC 250
Soustruh - karusel cnc EMAG VSC 250
EMAG VSC 250 lodret drejebænk med cnc
EMAG VSC 250 Karusselldrehmaschine CNC
κάθετος τόρνος πυργίσκου με cnc EMAG VSC 250
EMAG VSC 250 vertical turret lathe with cnc
Torno vertical cnc EMAG VSC 250
Tour vertical à cnc EMAG VSC 250
vertikalni revolver tokarski stroj sa CNC EMAG VSC 250
EMAG VSC 250 függőleges tornyos eszterga cnc-vel
Tornio verticale EMAG VSC 250
vertikalios bokštinės tekinimo staklės su cnc EMAG VSC 250
EMAG VSC 250 verticale draaibank met cnc
Tokarka karuzelowa CNC EMAG VSC 250
torno de torre vertical com cnc EMAG VSC 250
strung vertical cu turela cu cnc EMAG VSC 250
EMAG VSC 250 Вертикальный токарно-револьверный станок с ЧПУ
strug sa vertikalnim kupolom sa cnc EMAG VSC 250
EMAG VSC 250 vertikal revolversvarv med cnc
Dik taret Torna EMAG VSC 250
Get price & details
+34 679 …
Show phone
Details
About this seller
Specifications
Plate diameter
260 mm
Working height
mm
CNC type
Siemens SINUMERIK 840Dsl with integrated PLC S7-300
Max piece weight
6 kg
Rotation speed
4500 rpm
Engine Power
18 kW
Overhauled
no
Year of overhauling
-------------------
Length x width x height
3900.0
× 1500.0
× 3200.0
Weight
7000 kg
worked hours
hours under power
state
good
At local norms
---------
status
Datasheet
Emag VSC 250
Last availability date
24/04/2026
Show more
Automatic description (AI-Generated)
The EMAG VSC 250 is a vertical turret lathe manufactured in 2011, designed for precision machining tasks. It features a Siemens SINUMERIK 840Dsl CNC control system with integrated PLC S7-300, providing advanced operational capabilities. The machine measures 3900 mm in length, 1500 mm in width, and 3200 mm in height, with a total weight of 7000 kg.
Equipped with a spindle capable of reaching speeds up to 4500 rpm, the machine is powered by an 18 kW motor at 100% duty cycle, with a higher power rating of 28 kW at 40% duty cycle. It includes a robust hydraulic 6-jaw chuck from EMAG, model 6agf 260 k6 k14, with a diameter of 260 mm and a weight of 57 kg. The chuck provides maximum clamping forces of 12.8 kN for internal clamping and 4.2 kN for external clamping at 50 bar pressure. The workpiece capacity is up to 6 kg.
The machine features a flange turret with 12 tool positions (slots in storage), supporting efficient tooling changes. Its spindle torque is rated at 300 Nm, with driven tools capable of speeds up to 6000 rpm and torques up to 40 Nm (8.5 kW).
Additional specifications include X-axis and Z-axis movements of 745 mm and 300 mm respectively, with feed forces of 10 kN on both axes. Rapid traverse speeds are 60 m/min for X-axis and 30 m/min for Z-axis. The coolant system has a tank capacity of 360 liters and operates at a standard delivery pressure of 7 bar.
The machine includes a 15-inch TFT monitor and a V24 interface for connectivity. The exterior shows minor wear typical of industrial use, and the machining area exhibits some signs of use such as metal residue and discoloration. The machine is situated in an industrial workshop environment and appears clean and well-maintained overall. Multiple viewing windows on the machine body allow observation of the machining process. Electrical and control cabinet panels are located on the rear side, showing typical use wear but no visible damage.
This EMAG VSC 250 vertical turret lathe is suitable for precise and efficient machining operations in a variety of industrial settings. For further details or inquiries, please contact us.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Show more
Seller's description
This EMAG VSC 250 vertical turning machine was manufactured in 2011. It features a Siemens SINUMERIK 840Dsl control system, a robust hydraulic 6-jaw chuck, and a flange turret with 12 tool positions. With a spindle speed up to 4500 rpm and a main spindle drive power of 28kW at 40% duty cycle, it's ideal for precise, efficient operations. For more information about this vertical turning machine, please reach out to us.
Machine width: 1500 mm
Machine depth: 3900 mm
Machine height: 3200 mm
Machine weight: 7000 kg
CNC: Siemens SINUMERIK 840Dsl with integrated PLC S7-300
Spindle speed range: 4500 rpm
Spindle motor power: 18 kW (100% duty cycle), 28 kW (40% duty cycle)
Tool taper: DIN 55026 - A6
X-Axis Movement: 745 mm
X-Axis Feed Force: 10 kN
X-Axis Rapid Traverse: 60 m/min
Z-Axis Movement: 300 mm
Z-Axis Feed Force: 10 kN
Z-Axis Rapid Traverse: 30 m/min
Workpiece weight: 6 kg
Slots in storage: 12
Hydraulic 6-jaw special chuck from EMAG with face clamping device and central lubrication
15-inch TFT monitor
V24 interface
Spindle torque: 300 nm
Vdi shaft diameter: 40 mm
Maximum speed of driven tools: 6000 rpm
Maximum torque of driven tools: 40 nm / 8. 5 kw
Coolant system standard delivery pressure: 7 bar maximum delivery pressure: 7 bar internal coolant supply pressure range: 7 bar (non-adjustable) coolant tank capacity: 360 liters
Chuck model: 6agf 260 k6 k14
Chuck diameter: 260 mm
Chuck weight: 57 kg
Maximum clamping force for internal clamping (50 bar): 12. 8 kn
Maximum clamping force for external clamping (50 bar): 4. 2 kn
Machine from single-shift operation
Maximum room temperature: up to 30°c
Maximum humidity: 50%
Sound pressure level: 78 db(a)
Machine still under power
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
