GIANA GGL650 CNC CNC lathe

Lathe
Type
CNC
Brand
GIANA
GGL650 CNC
Capacity
ø1240x2000 mmø48.82x78.74 in
Technical specifications
Convert toMetricImperial
WORKING AREA
Center height
155
Max turning diameter on bed
1240 mm48.82 in
Max turning diameter on carriage
850 mm33.46 in
Distance between centers
2000 mm78.74 in
Bed width
650 mm25.59 in
Groove length
2 mm0.08 in
Max weight between centers
10,000 Kg
FLAT BED
Bed width
650 mm25.59 in
Number of guides
2
CNC
CNC
FAGOR 8055
MAIN SPINDLE
Max rotation speed
1000 rpm
Spindle nose
ASA11/15”
Spindle bore
155 mm6.10 in
Max torque
10,000 Nm
Max power
40/60 Kw
Self-centering diameter
800 mm31.50 in
TAILSTOCK
Quill diameter
155 mm6.10 in
Quill travel
300 mm11.81 in
Quill Morse taper
CM6
TURRET
Number of positions
4
EXTRA
Chip conveyor
2
Platform
ø800mm
Steady rest passage on carriage
1x ø650mm, 1x ø390mm
Protections
yes
