Multi Spindle Drilling Machines DMG MORI CLX 450
71430.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Swing diameter over guide ways | 650 mm |
| Swing diameter over transverse guideway | 465 mm |
| Turning diameter | 315 mm |
| Bar diameter max. | 80 mm |
| Longitudinal stroke | 600 mm |
| Transverse stroke | 267 mm |
| Y axis, vertical | +/- 60 mm |
| Rapid traverse in X | 30 m/min |
| Rapid traverse in Z | 30 m/min |
| Rapid traverse in Y | 10 m/min |
| Drive power (100% DC) | 17 kW |
| Drive power (40% DC) | 25,5 kW |
| Speed range | - 4000 rpm |
| Torque (100% DC) | 283 Nm |
| Max. torque (40% DC) | 426 Nm |
| C-Axis Speed | -100 rpm |
| Torque of C-Axis (holding torque) | 370 Nm |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 40 mm |
| Number of driven tools | 12 |
| Speed max. | -4000 rpm |
| Power max. (40% DC) | 5,44 kW |
| Dimensions (L x W x H) | 3,0 x 2,66 x 1,94 (4,18 x 2,66 x 1,94) m |
| Weight approx. | 5800 Kg |
| Pre-setting Package | Pre-setting Package: - tool pre-setting probe - chip conveyor instead of chip tank - 4 colour signal lamp |
| Cooling pump, 12 bar | Reinforced cooling pump, 12 bar |
| Direct measuring system for X-Axis | Direct measuring system for X-Axis Note: Option suitable only for machine in V1, V3 and V4 version |
| Clamping with balanced pressure for main spindle | Clamping with balanced pressure for main spindle with standard hydraulic cylinder. Max. bar capacity: D 80 mm |
| Special equipment | - Gantry Loader GX06 - Rotary magazine with 10 pallet station - 3 finger centring gripper |
| 2020 | DMG MORI |
| 2022 | DMG MORI |
| 2021 | DMG MORI |
| 2019 | DMG MORI |
| 2024 | DMG MORI |
| 2023 | DMG MORI |
| 2012 | DMG MORI |
| 2017 | DMG MORI |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071581
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:168881187]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071581
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:168881187]
