Multi Spindle Drilling Machines DMG MORI CLX 450
71430.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Swing diameter over guide ways | 700 mm |
| Clamping chuck diameter max. | 315 mm |
| Spindle bore | 91 mm |
| Bar diametre | 80 mm |
| Spindle diametre on front bearing | 130 mm |
| Drive power (40% DC) | 25,5 kW |
| Drive power (100% DC) | 17 kW |
| Speed range | - 4000 rpm |
| Torque (100% DC) | 283 Nm |
| Max. torque (40% DC) | 426 Nm |
| C-Axis Speed | -200 rpm |
| Longitudinal stroke | 830 mm |
| Transverse stroke | 271 mm |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 40 mm |
| Number of driven tools | 12 |
| Speed max. | -4000 rpm |
| Power max. (40% DC) | 5,44 kW |
| Dimensions (L x W x H) | 3,26 x 2,44 x 1,95 (4,5 x 2,44 x 1,95) m |
| Weight approx. | 6300 Kg |
| Pre-setting Package | Pre-setting package: Option includes: - tool pre-setting probe MARPOSS - chip conveyor with right side discharge instead of chip tank - signal lamp with 4 colours |
| Hydr. chuck, type Samchully MH-210, D 82 mm | Hydraulic 3-jaw chuck D254 mm SAMCHULLY MH-210 Option includes set of hard jaws and connecting elements Chuck through hole: D82 mm |
| 2021 | DMG MORI |
| 2020 | DMG MORI |
| 2022 | DMG MORI |
| 2019 | DMG MORI |
| 2024 | DMG MORI |
| 2023 | DMG MORI |
| 2012 | DMG MORI |
| 2017 | DMG MORI |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071637
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:166605821]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071637
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:166605821]
