Multi Spindle Drilling Machines DMG MORI CTX 2500|1250
34900.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Swing diameter over guide ways | 710 mm |
| Clamping chuck diameter max. | 315 mm |
| Longitudinal stroke | 1345 mm |
| Transverse stroke | 260 mm |
| Spindle bore | 91 mm |
| Spindle diametre on front bearing | 140 mm |
| Drive power (100% DC) | 22 kW |
| Speed range | - 4000 rpm |
| Torque (100% DC) | 410 Nm |
| Max. torque (40% DC) | 525 Nm |
| Accuracy at point stopping | 0,001 degree |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 40 mm |
| Number of driven tools | 12 |
| Speed max. | -6000 rpm |
| Power max. (100% DC) | 10 kW |
| Weight approx. | 7800 Kg |
| Dimensions (L x W x H) | 5,4 x 2,07 x 2,6 m |
| Plug-in board with 2x4 free in-/outputs | Inputs / outputs programmable via M-functions, consisting of: 8 inputs 4 outputs, 2 amperes 4 outputs, potential-free |
| Excentric turning and milling operation | Excentric turning and milling operation (only with Siemens control) |
| Technologie cycle alternating speed | Technology cycle for the application of an alternating speed for vibration sensitive set-ups (Only in conjunction with Siemens control) |
| Polygon Turning | Polygon Turning for machining of elliptic and polygonal shapes on end faces Note: Only in combination with option B-A0326 Excentric turning and milling operation |
| DXF-Reader for Siemens | DXF-Reader for Siemens direct on the control for the import of DXF-files as contour or position sample. - support of layer and colours - selection of geometry elements |
| Dynamic two-pressure clamping at the control, MS | Dynamic two-pressure clamping at the control for the main spindle The clamping pressure can be specified by NC program |
| Dyn. two-pressure clamping, motor-adj. valves CS | Dynamic two-pressure clamping for the counter spindle with motor-adjustable valves The clamping pressure can be specified by the NC program |
| Coolant/compressed air switchable on tool carrier | Cooling lubricant and compressed air switchable on the turret - Compressed air feed to the turret, switchable from cooling lubricant to compressed air by M-function |
| Steady rest SMW K2, clamping range 25-180 mm | Steady rest SMW K2, clamping range 25-180 mm (0.9-7.08 in), self centering, hydraulical actuated (Note: additional steady rest slide and steady rest carrier required) |
| Steady rest carrier for steady rest, 25-180 mm | Steady rest carrier for steady rest, clamping range 25-180 mm (0.9-7 in) |
| Quick change system for steady rest | Quick change system for steady rest, 2-fold cone centering between steady rest slide and steady rest carrier |
| Double cartridge filter on chip conveyor | Double cartrige filter on chip conveyor |
| Filter element for double cartridge filter | Filter element for double cartridge filter, Mahle or Hydac Number of units: 1 Notice: These are reusable metal filters that can be cleaned in an ultrasonic bath |
| Hinged type chip conveyor | Hinged typ chip conveyor incl. coolant tank and coolant pump, 6 bar (87 psi)/20 litre/min |
| Mechanical oil mist extractor 1100m³/h | Mechanical oil mist extractor, 1100 m³/h (38,830 ft³/h) with dirtiness indicator, class of filtration H13 |
| Tool measuring dev. for main spindle, manu., Ø400 | Tool measuring device in the working area for the main spindle with touch probe RP3 from Renishaw, manually plugable up to chuck diameter Ø400 mm (15.7 in) |
| 3-jaw chuck, KNCS-N 400-128, make SMW | 3-jaw power clamping chuck with through-hole and jaw quick-change system type KNCS-N 400-128, make SMW-Autoblok, incl. connecting elements |
| Set base jaws, 3 pieces, Ø 400 | Set (3 pieces) of basic jaws for chuck Ø400 mm (Ø15.75 in), for jaw quick-change system |
| 3-jaw chuck, KNCS-N 225-66, make SMW | 3-jaw power clamping chuck with through-hole and jaw quick-change system type KNCS-N 225-66, make SMW, incl. connecting elements |
| Set base jaws, 3 pieces, Ø 200/225 | Set (3 pieces) of basic jaws for chuck Ø200 / 225 mm (Ø7.87/8.85 in), for jaw quick-change system |
| Tool holder package Quickchange, VDI 40, star, WTO | Tool holder package Quickchange, WTO for star turret VDI 40 |
| Fixing elements | Four fixing elements for dowelling the machine |
| Package for tropical climate (ambient temp.50ºC) | Package for tropical climate for ambient temperature of max. 50ºC at machine location, consisting of cooling system for control cabinet (until 50º) and machine |
| Window rising of the security windows | Window cleaning of the security windows of both working area doors by compressed air (Remark: The employment of coolant can limited the view on the workpiece at machining) |
| proTIME | proTIME Visualisation of the remaining runtime, remaining workpieces and the machine state |
| Package for instable supply | Package for instable supply consisting of under voltage circuit-breaker and Z-axis / Z-axes feed motor (s) with brake (s) |
| Enlarged container for slideway oil, 6l | Enlarged container for slideway oil with a container size of 6 l (1.58 gal) |
| Minimess test point couplings for hydraulic | Minimess test point couplings for hydraulic Minimess connections (M16x2) before and after all hydraulic actuators for monitoring and diagnosis |
| Hydraulic oil level and temperature monitoring | Hydraulic oil level and temperature monitoring - Electrical level monitoring with prewarning - For external evaluation potential-free contacts available |
| Part Analyzer for CELOS V6 on machine | Part Analyzer for CELOS V6 on machine Control site CAD measurement functionality to maintain high quality standards. |
| Part Analyzer for CELOS PC version 6 | Part Analyzer for CELOS PC-Version V6 Control site CAD measurement functionality to maintain high |
| CELOS PC-Version 6 | CELOS PC-Version 6 CELOS PC-Version is the perfect addition for your job preparation supporting your CELOS machines. |
| DMG MORI SMARTkey Masterkey | DMG MORI SMARTKey® - Masterkey replaces key switch for CELOS® / SLIMline® 4 control panel |
| DMG MORI SMARTKey - Turning/Milling | DMG MORI SMARTkey® Turning/ Milling package for CELOS® / SLIMline® 4 contol panel |
| Cover plate gripper interface | Cover plate and equipment for use of the robot with only one equipped gripper |
| Pressure piece | Elastic pressure piece for compensation angle errors at sawing sections |
| Workpiece tray Ø170 mm, 16 positions | Workpiece tray for max. 16 parts up to Ø 170 mm (6.6 in), consisting of: - 1x honeycomb sheet as basic tray - 1x honeycomb sheet as height- adjustable support up to 130 mm (5.1 in) |
| Stacking tray Ø170 mm, 15 positions | Workpiece tray with simple stacking function for max. 15 parts with Ø105 - 170 mm (4.1 - 6.6 in) per level, consisting of: - Basic tray - 80 mm (3.1 in) high support designed as double stop |
| Additional 4-jaw gripper | Additional 4-jaw gripper for: - Shaft parts - Outside handle 25kg and 35kg module: Diameter 20-150 mm (shaft) (0.78-5.9 in) |
| SERVICEcamera | SERVICEcamera Camera set incl. accessories (Antenna, charger, incl. SD card) |
| Service Agent | Service Agent Overview of all maintenance work on the machine |
| Pressure adjustment | Pressure adjustment - Manual adjustment of gripping pressure for each gripper(A and B) individually in the range of 2.5 - 6 bar - Mounted on robot arm |
| Hoist | Hoist for the transport of the complete system by a crane, consisting of: - 3 attachment points |
| 2 x Additional feet | 2 x Additional feet - 1 set (3 pieces) set-up elements |
| Robot in white exterior paint | Robot in special paint calcite white (RAL 9010) |
| Attention: Preparation for automation is necessary | Attention: Preparation for automation is necessary For the connection of the Robo2Go the machine needs to be prepared with the electrical interface. |
