Multi Spindle Drilling Machines DMG MORI CTX 2500|700
34900.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Swing diameter over guide ways | 620 mm |
| Transverse stroke | 260 mm |
| Longitudinal stroke | 795 mm |
| Clamping chuck diameter max. | 315 mm |
| Spindle bore | 91 mm |
| Spindle diametre on front bearing | 140 mm |
| Drive power (100% DC) | 22 kW |
| Speed range | - 4000 rpm |
| Max. torque (40% DC) | 525 Nm |
| Torque (100% DC) | 410 Nm |
| Accuracy at point stopping | 0,001 degree |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 40 mm |
| Number of driven tools | 12 |
| Speed max. | -6000 rpm |
| Power max. (100% DC) | 10 kW |
| Dimensions (L x W x H) | 3,99 x 2,03 x 2,2 m |
| Weight approx. | 6500 Kg |
| Technologie cycle alternating speed | Technology cycle for the application of an alternating speed for vibration sensitive set-ups (Only in conjunction with Siemens control) |
| DXF-Reader for Siemens | DXF-Reader for Siemens direct on the control for the import of DXF-files as contour or position sample. - support of layer and colours - selection of geometry elements |
| Chuck rinsing device, outside | chuck rinsing device, outside (main spindle) |
| Chuck rinsing device, outside, counter spindle | Chuck rinsing device for counter spindle, outside |
| Dyn. two-pressure clamping, motor-adj. valves CS | Dynamic two-pressure clamping for the counter spindle with motor-adjustable valves The clamping pressure can be specified by the NC program |
| Coolant/compressed air switchable on tool carrier | Cooling lubricant and compressed air switchable on the turret - Compressed air feed to the turret, switchable from cooling lubricant to compressed air by M-function |
| Reinforced coolant pump, 5 - 20 bar | Reinforced coolant pump, 5 - 20 bar, adjustable with frequency variation in addition to the standard pump |
| Double cartridge filter on chip conveyor | Double cartrige filter on chip conveyor |
| Extension of the discharge chute about 300 mm | Extension of the discharge chute at the chip conveyor about 300 mm |
| Hinged type chip conveyor | Hinged typ chip conveyor incl. coolant tank and coolant pump, 6 bar (87 psi)/20 litre/min |
| Tool measuring dev. in working area, manually,Ø315 | Tool measuring device in the working area with touch probe TT30 from Marposs, manually swiveling, up to chuck diameter Ø 315 mm (12.4 in) |
| 3-jaw chuck, BBD 250-78, make SMW | 3-jaw power clamping chuck with through-hole, type BBD 250/78, make SMW-Autoblok incl. connecting elements |
| 3-jaw chuck, BBD 175-56, make SMW | 3-jaw power clamping chuck with through-hole, type BBD 175/56, make SMW-Autoblok, incl. connecting elements |
| proTIME | proTIME Visualisation of the remaining runtime, remaining workpieces and the machine state |
| Ligh switch cabinet | Ligh switch cabinet (fluoresent lamp starterless) with integrated socket, 230 V, 2 A load, make Rittal on lott via Transformer chead main switch |
| Package for increased ambient temperature | Package for increased ambient temperature consisting of cooling system for control cabinet (until 40º) |
| Service Agent | Service Agent Overview of all maintenance work on the machine |
| 2018 | DMG MORI |
| 2014 | DMG MORI |
| 2020 | DMG MORI |
| 2017 | DMG MORI |
| 2009 | DMG MORI |
| 2015 | DMG MORI |
| 2016 | DMG MORI |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071558
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:166605808]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071558
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:166605808]
