Multi Spindle Drilling Machines DMG MORI CTX alpha 500
97000.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Swing diameter over guide ways | 500 mm |
| Transverse stroke | 210 mm |
| Longitudinal stroke | 525 mm |
| Clamping chuck diameter max. | 210 mm |
| Drive power (100% DC) | 13 kW |
| Speed range | 20 - 6000 rpm |
| Torque (100% DC) | 171 Nm |
| C-Axis Speed | -300 rpm |
| Torque of C-Axis (holding torque) | 192 Nm |
| Spindle nose | Flat flange |
| Diametre of spindle nose | 140h5 mm |
| Spindle bore | 73 mm |
| Spindle diametre on front bearing | 100 mm |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 30 mm |
| Number of driven tools | 12 |
| Speed max. | -5000 rpm |
| Power max. (40% DC) | 4,2 kW |
| Dimensions (L x W x H) | 3,66 x 2,58 x 1,83 m |
| Weight approx. | 4800 Kg |
| Design version BLACK | Design version BLACK Working area door, front cover beneath Working area door and front pane frame in colour deep black |
| Reinforced coolant pump, 12bar,23l/min | Reinforced coolant pump 12 bar, 23 l/min (174.04 psi, 6.07 gal) instaed of 6 bar, 20 l/min (87.02 psi, 5.28 gal) |
| Hinged type chip conveyor CTX alpha | Hinged type chip conveyor incl. coolant tank and coolant pump, 6 bar (87 psi)/20 litre/min |
| Tool gauging device in the working area | Tool gauging device in the working area, manually swivellable |
| Service Agent | Service Agent Overview of all maintenance work on the machine |
| 2021 | DMG MORI |
| 2010 | DMG MORI |
| 2012 | DMG MORI |
| 2003 | DMG MORI |
| 2004 | DMG MORI |
| 2014 | DMG MORI |
| 2009 | DMG MORI |
| 2015 | DMG MORI |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071714
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:166896778]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:071714
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:166896778]
