Multi Spindle Drilling Machines DMG MORI NEF 520
37500.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Type of main drive | AC |
| Drive power (100% DC) | 12 kW |
| Speed range | 10 - 3000 rpm |
| Number of Gearsteps | 2 |
| Max. torque (40% DC) | 920 Nm |
| Swing diameter over guide ways | 500 mm |
| Swing diameter over transverse guideway | 285 mm |
| Centre height | 1000 mm |
| Transverse stroke | 260 mm |
| Spindle nose | acc. To DIN 55027 |
| Diametre of spindle nose | 8 |
| Spindle bore | 70 mm |
| Spindle diametre on front bearing | 120 mm |
| Rapid traverse in X | 8 m/min |
| Rapid traverse in Z | 10 m/min |
| Feed rate in X | 5000 mm/min |
| Feed rate in Z | 5000 mm/min |
| Feed rate torque (100% DC) in X | 500 daN |
| Feed rate torque (100% DC) in Z | 1000 daN |
| Dimensions (L x W x H) | 3,1 x 1,95 x 1,83 m |
| Weight approx. | 2900 Kg |
| Disk turret, Sauter, DIN 69880-30 mm | Disk turret, 8 stations for fix tools, make Sauter, tool reception DIN 69880-30 mm mounted behind the center line (Attention: The working area will changed). |
| 2009 | DMG MORI |
| 2011 | DMG MORI |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:015527
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:168864454]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:015527
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:168864454]
