Multi Spindle Drilling Machines DMG MORI T2
VB
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2019 |
| Swing diameter over bed | 650 mm |
| Swing diameter over X linear guideways | 520 mm |
| Max machining diameter | 460 mm |
| Clamping chuck Ø | 254 mm |
| X travel | 300 mm |
| Z travel | 730 mm |
| Type of main drive | AC |
| Drive power (100% DC) | 15 kW |
| Drive power (40% DC) | 19,5 kW |
| Speed range | -3500 rpm |
| Torque (100% DC) | 246 Nm |
| Max. torque (40% DC) | 319 Nm |
| Spindle nose | A2-8 |
| Spindle diametre on front bearing | 140 mm |
| Spindle bore | 91 mm |
| Bar diameter max. | 80 mm |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 40 mm |
| Signal lamp with 4 colours standard | Signal lamp with 4 colours Red: general error Yellow: intervention necessary Green: automatic mode Blue: setup mode |
| Alternative Speed Turning | Technology cycle Alternate Spindle Speed (Turning) for the application of an alternate speed for vibration sensitive set-ups. |
| Easy Tool Monitor Fanuc | Tool monitoring software device by Fanuc CNC |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:075157
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:169371060]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:075157
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
RESALE member since 2019
---
[SRC:resale:169371060]
