SCHUTTE SE16 Multispindle automatic lathe

SCHUTTE SE16 Multispindle automatic lathe
Verified seller
Price on request
Make an offer
Manufacturer
SCHUTTE
Model
SE16
Year
Location
Italy
Category
Lathes - CNC multi-spindle lathes
Product id
P241211372
Buy this machine
Language
Language
Многошпинделен автоматичен струг SCHUTTE SE16
Multivřetenový automatický soustruh SCHUTTE SE16
SCHUTTE SE16 Multispindlet automatisk drejebænk
SCHUTTE SE16 Automatische Mehrspindel-Drehmaschine
Αυτόματος τόρνος πολλαπλών αξόνων SCHUTTE SE16
SCHUTTE SE16 Multispindle automatic lathe
Torno multihusillos automático SCHUTTE SE16
Tour multibroche SCHUTTE SE16
Viševreteni automatski strug SCHUTTE SE16
SCHUTTE SE16 Többorsós automata eszterga
Tornio multimandrino SCHUTTE SE16
Daugialypės automatinės tekinimo staklės SCHUTTE SE16
SCHUTTE SE16 Meerassige automatische draaibank
Wielowrzecionowy automat tokarski SCHUTTE SE16
Torno automático multifuso SCHUTTE SE16
Strung automat cu mai multe arbori SCHUTTE SE16
SCHUTTE SE16 Многошпиндельный токарный станок
Automatski strug sa više vretena SCHUTTE SE16
SCHUTTE SE16 Flerspindlig automatisk svarv
Otomatik çok milli torna tezgahı SCHUTTE SE16
Get price & details
+39 3 51…
Show phone
Details
About this seller
Specifications
Max. Ø
16 mm
Nbr of spindles
6
Type of CNC
Spindle speed
5000 rpm
Spindle power
11 kW
-------------------
Length x width x height
3600.0
× 1300.0
× 1800.0
Weight
5000 kg
worked hours
hours under power
state
as-is, where-is
At local norms
---------
status
visible
Last availability date
04/05/2026
Show more
Automatic description (AI-Generated)
This SCHUTTE SE16 is an automatic multispindle lathe designed for efficient and precise machining of metal bars. It features six spindles arranged on a multispindle turret, allowing simultaneous operations to increase productivity. The machine supports a maximum bar diameter of 16 mm and can accommodate bar feeding lengths up to 120 mm. The spindle speed ranges from 400 to 5000 rpm, powered by an 11 kW motor, providing sufficient power for various turning tasks.
The lathe offers longitudinal slide travels of 80 mm total and 63 mm working travel, while the transversal slides have distinct travels: the upper slide moves 42 mm total with 29 mm working travel, the central slide 54 mm total with 29.5 mm working travel, and the lower slide 60 mm total with 31.9 mm working travel. These travel ranges facilitate versatile machining operations on different parts of the workpiece.
The machine's normal working cycle time is approximately 1.25 seconds, supporting high throughput in production environments. It includes accessories such as tube stands and a tube cover, which help in material handling and protection during operation.
Visual inspection confirms the presence of the multispindle turret with six spindles and cutting tools mounted on tool holders around the turret. A metal workpiece is currently mounted in the center spindle, indicating readiness for machining. The machine shows typical signs of use, including metal shavings and oil residues, but no visible damage or broken parts on the turret or tools. Overall, this SCHUTTE SE16 multispindle lathe is a robust and capable machine suitable for precision bar turning tasks in industrial settings.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Show more
Seller's description
Automatic multispindle lathe
Bar size diameter 16 mm (18 mm).
Max bar feeding 120 mm.
Longitudinal slides travel (corsa tot./di lavoro) 80/63 mm.
Transversal slides travel (tot. Travel/working travel):
upper 42/29 mm
central 54/29,5 mm
lower 60/31,9 mm
N. 6 spindles.
Nr. 45 speed spindles.
Spindles speed 400-5000 rpm
Normal working times 1,25 sec.
Dragging motor power 11 kW.
Dragging speed motor 1500 rpm
Devices and Accessories: Tube/stands – Tube Cover
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
