Index ABC CNC lathe
49.00 €
Договорная
| Состояние | gebraucht |
|---|---|
| Производитель | Siemens |
| Год выпуска | 2017 |
| Manufacturer | Index |
| Model | ABC |
| Year | 2017 |
| Location | Germany |
| Category | Lathes - CNC lathes |
| Turning length | 400 mm |
| Turning Ø | 200 mm |
| X-axis | 155 mm |
| Z-axis | 590 mm |
| Spindle bore | 42 mm |
| Number of turrets | 2 |
| Number of tools on turret | 14 |
| Number of rotating tools | 14 |
| Turning speed | 6000 rpm |
| Spindle motor power | 20 kW |
| Tailstock | no |
| Bar feeder | yes |
| Length x width x height | 2830.0 × 1500.0 × 2200.0 |
| Weight | 3500 kg |
| state | as-is, where-is |
| At local norms | yes |
| Datasheet | Index ABC |
| Last availability date | 08/09/2026 |
| Product id | P260907027 |
| Client type | Machinery dealer |
| Active since | 2022 |
| Offers online | 50 |
| Last activity | Sept. 24, 2026 |
| Type of CNC | Siemens |
| Spindle taper | HSK A63 |
| Ø above the bed | 400 mm |
| Length between centers | 400 mm |
| Max workpiece weight | 5 kg |
| Ø above transversing slide | 420 mm |
Описание
Condition: Used
Manufacturer: Index
Model: ABC
Year of Manufacture: 2017
Machine Type: CNC Short-Bed Lathe
Control System: Fanuc 32i-B
Operational Status: Fully functional
Spindle Bore: Ø 42 mm
X-axis Travel: 90 mm
Z-axis Travel: 280 mm
Rapid Traverse X: 27 m/min
Rapid Traverse Z: 36 m/min
Upper Turret (Main Tool Carrier): 8 stations (including 1 synchronizable)
Tool Holder: VDI 25
Supports Powered Tools: Yes
Lower Turret: 6 stations
Rear Side: 5 stations for rear machining
Simultaneous Machining: Up to 3 tools simultaneously
Coolant System & Chip Conveyor: IRCO ILS MUK 7012-II bar loader, built in 2015
Machine Dimensions: 2830 × 1500 × 2200 mm
Machine Weight: 3500 kg
Coolant System & Chip Conveyor Dimensions: 1600 × 1250 × 1780 mm
Coolant System & Chip Conveyor Weight: 680 kg
Bar Loader: IRCO ILS MUK, Dimensions 1800 × 1000 × 1280 mm
Bar Loader Weight: 650 kg
Notes: The machine is fully functional and in good used condition. Inquiries welcome. Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
Manufacturer: Index
Model: ABC
Year of Manufacture: 2017
Machine Type: CNC Short-Bed Lathe
Control System: Fanuc 32i-B
Operational Status: Fully functional
Spindle Bore: Ø 42 mm
X-axis Travel: 90 mm
Z-axis Travel: 280 mm
Rapid Traverse X: 27 m/min
Rapid Traverse Z: 36 m/min
Upper Turret (Main Tool Carrier): 8 stations (including 1 synchronizable)
Tool Holder: VDI 25
Supports Powered Tools: Yes
Lower Turret: 6 stations
Rear Side: 5 stations for rear machining
Simultaneous Machining: Up to 3 tools simultaneously
Coolant System & Chip Conveyor: IRCO ILS MUK 7012-II bar loader, built in 2015
Machine Dimensions: 2830 × 1500 × 2200 mm
Machine Weight: 3500 kg
Coolant System & Chip Conveyor Dimensions: 1600 × 1250 × 1780 mm
Coolant System & Chip Conveyor Weight: 680 kg
Bar Loader: IRCO ILS MUK, Dimensions 1800 × 1000 × 1280 mm
Bar Loader Weight: 650 kg
Notes: The machine is fully functional and in good used condition. Inquiries welcome. Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
