BIGLIA B1200Y cnc lathe
Verified seller
Price on request
Make an offer
Manufacturer
BIGLIA
Model
B1200Y
Year
2008
Location
Italy
Category
Lathes - CNC lathes
Product id
P240226001
Buy this machine
Language
Language
cnc струг BIGLIA B1200Y
Soustruh cnc BIGLIA B1200Y
cnc drejebænk BIGLIA B1200Y
BIGLIA B1200Y Drehmaschine CNC
cnc τόρνος BIGLIA B1200Y
BIGLIA B1200Y cnc lathe
Torno cnc BIGLIA B1200Y
Tour cnc BIGLIA B1200Y
cnc tokarski stroj BIGLIA B1200Y
BIGLIA B1200Y cnc eszterga
Tornio cnc BIGLIA B1200Y
cnc tekinimo staklės BIGLIA B1200Y
BIGLIA B1200Y cnc-draaibank
Tokarka CNC BIGLIA B1200Y
Torno CNC BIGLIA B1200Y
strung cnc BIGLIA B1200Y
BIGLIA B1200Y Токарный станок с ЧПУ
cnc strug BIGLIA B1200Y
BIGLIA B1200Y cnc svarv
Cnc torna BIGLIA B1200Y
Get price & details
+39 030 …
Show phone
Details
About this seller
Specifications
Turning length
1315 mm
Ø above the bed
700 mm
Ø above transversing slide
410 mm
Type of CNC
Fanuc 18i-TB
Z-axis
315 mm
Spindle taper
ASA8”
Spindle bore
111 mm
Number of tools on turret
12
Turning speed
2800 rpm
Spindle motor power
30 kW
Tailstock
no
Bar feeder
no
-------------------
Length x width x height
5100.0
× 2000.0
× 2100.0
Weight
7250 kg
worked hours
hours under power
state
good
At local norms
yes
status
visible
Last availability date
23/04/2026
Show more
Automatic description (AI-Generated)
This is a BIGLIA B1200Y CNC lathe machine, manufactured in 2008, designed for precision turning operations. The machine offers a maximum turning length of 1315 mm and can handle diameters up to 700 mm above the bed, 410 mm above the transversing slide, and 92 mm from bar stock. It features a robust spindle bore of 111 mm and a spindle motor power of 30 kW, delivering a maximum rotational speed of 2800 rpm. The lathe is equipped with a 12-position turret, allowing for efficient tool changes, with motorized tool speeds up to 4000 rpm and power of 5.5 kW per tool. The machine's axes provide ample travel: 255 mm on the X1 axis, 1315 mm on the Z1 axis, and 110 mm (+60/-50) on the Y1 axis, with rapid traverse rates enhancing productivity. Additional features include a C-axis with 0.001° resolution and speeds up to 100 rpm, a tailstock with a 115 mm quill diameter and 150 mm stroke, and a B-axis travel of 1200 mm. The machine weighs approximately 7250 kg and measures 5100 mm in length, 2000 mm in width, and 2100 mm in height. It is equipped with a chip conveyor and provisions for a hydraulic steady rest. The exterior of the machine is well-maintained, painted white with blue stripes, and bears the Biglia branding. Two viewing windows provide visibility into the machining area. Power cables and air hoses are connected at the base, indicating readiness for operation. This lathe is housed indoors in a well-lit industrial workshop environment. Fixed and motorized tool holders are available, supporting versatile machining tasks. Overall, the BIGLIA B1200Y is a substantial CNC lathe suitable for demanding turning applications requiring precision and flexibility.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Show more
Seller's description
Capacity: 92/410x1315 mm
Year of construction: 2008
Working range Max machinable diameter from bar: 92 mm
Max machinable diameter from shot: 410 mm
Max machinable diameter on the bench: 700 mm
Max machinable length: 1315 mm
Cnc Cnc: Fanuc 18i-TB
Notes: Manual Guide, SBS, Anti-collision,
Main spindle Max rotational speed: 2800 rpm
Spindle Nose: ASA8â€
Spindle Bore: 111 mm
Bearing inside diameter: 150 mm
Self-centering diameter: 315 mm
Max power: 30 Kw
Max. torque: 776 Nm
C-axis resolution: 0.001 °
C-axis speed: 100 Rpm
Tailstock quill diameter: 115 mm
Tailstock stroke: 150 mm
Cone: CM5
B-axis travel: 1200 mm
Carriage: bezel carriage to follow
Turret 1 Number of positions: 12
Rotation time (1 pos): 0.15 sec.
Number of motorized positions: 12
Motorized tool speed: 4000 rpm
Motorized tool power: 5.5 Kw
Motorized tool torque: 70 Nm
X1 axis travel: 255 mm
Rapid x1 axis: 20 m/min
Z1 axis stroke: 1315 mm
Rapid z1 axis: 24 m/min
Travel y1 axis: 110 (+60/-50) mm
Rapid y1 axis: 7.5 m/min
Total machine weight: 7250 kg
Machine overall dimensions: 5100x2000x2100 mm
Hydraulic steady rest: provision for steady rest
Fixed tool holders: available
Motorized toolholders: available
Self centering: 315
Chip conveyor: yes
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
