SF32 Multispindle автоматичний токар

SCHÜTTE SF32 Multispindle automatic lathe
View price
SCHÜTTE
SF32
1985
Italy
Lathes - CNC multi-spindle lathes
P250209116
+39 3 51…
Max. Ø
32 mm
Nbr of spindles
6
Max. length
300 mm
Type of CNC
Length x width x height
3850.0 × 1390.0 × 2200.0
Weight
8500 kg
revised
visible
04/05/2026
This Schütte SF32 multispindle automatic lathe, manufactured in 1985, is designed for efficient machining of bar stock with a maximum diameter of 32 mm and a maximum length of 300 mm between spindle axes. The machine features six spindles, allowing simultaneous processing of multiple parts to increase productivity. It has a compact footprint with dimensions of 3850 mm in length, 1390 mm in width, and 2200 mm in height, and weighs approximately 8500 kg. The lathe is equipped with an enclosed machining area accessible via a blue door with a window, enabling safe operation while allowing the operator to monitor the machining process. The control panel, mounted on the right side, comprises multiple buttons, switches, indicator lights, and an emergency stop button, facilitating comprehensive machine control. Labels on the control panel indicate various functions, and the panel shows minor signs of wear consistent with use. The machine includes several cross slides with travel distances: upper slide 50/33 mm, central slide 50/30 mm, and lower slide 60/37.5 mm. It offers a spindle speed range from 200 to 3150 rpm across 49 speed settings, with working times between 0.63 and 200 seconds and idle times from 0.7 to 1.25 seconds. Additional equipment includes a Tube+Stand stand with a hydraulic system, a smoke extractor, a recessing device, an additional oil collection tank, a workpiece unloading device with a conveyor belt, and a fire-fighting system. The machine is controlled via a SIMATIC HMI Siemens PLC integrated with a Nordmann tool monitor, and an accessories box is provided. The lathe's interior shows signs of active use, with visible metal shavings, coolant, and machining residue present. Components, including tooling and hydraulic/pneumatic lines, appear intact but used. The exterior exhibits some paint wear and dirt accumulation, especially on the base and door. A Donaldson Torit DCE filtration unit is mounted above the machine to support dust and chip extraction. The chip collection area contains metal shavings and shows evidence of regular operation. Overall, this Schütte SF32 multispindle lathe is a robust machine suitable for high-volume production environments, equipped with multiple accessories to support efficient and safe machining operations. Automatic multispindle lathe
6 spindles
Bar size diameter: 32 mm
Diameter Between spindle axes: 300 mm
Bar feed:
normal: 125 mm,
special: 290 mm
longitudinal: 100/80 mm. Cross slides travel:
upper slide 50/33 mm
central slide 50/30 mm
lower slide 60/37,5 mm
No. spindle speed: 49
Spindle speed: min 200/min – max 3150/min
Working time: min 0,63 sec – max 200 sec
Idle time: min. 0,7 sec – max 1,25 sec
Dispositivi e Accessori: Tube+Stand stand with hydraulic system – Smoke extractor – Recessing device – Additional oil collection tank – Workpiece unloading device with conveyor belt – Fire-fighting system – SIMATIC HMI SIEMENS PLC with Nordmann tool monitor – Accessories box – Control unit
