SPINNER TC800L 110 CNC верстат

SPINNER TC800L 110 CNC lathe
Top seller
Price on request
Make an offer
Manufacturer
SPINNER
Model
TC800L 110
Year
2023
Location
Germany
Category
Lathes - CNC lathes
Product id
P260402079
Buy this machine
Language
Language
CNC струг SPINNER TC800L 110
CNC soustruh SPINNER TC800L 110
SPINNER TC800L 110 CNC-drejebænk
SPINNER TC800L 110 CNC-Drehmaschine
Τόρνος CNC SPINNER TC800L 110
SPINNER TC800L 110 CNC lathe
Torno CNC SPINNER TC800L 110
Tour CNC SPINNER TC800L 110
CNC tokarski stroj SPINNER TC800L 110
SPINNER TC800L 110 CNC esztergagép
Tornio CNC SPINNER TC800L 110
SPINNER TC800L 110 CNC tekinimo staklės
SPINNER TC800L 110 CNC-draaibank
Tokarka CNC SPINNER TC800L 110
Torno CNC SPINNER TC800L 110
Strung CNC SPINNER TC800L 110
SPINNER TC800L 110 Токарный станок с ЧПУ
CNC strug SPINNER TC800L 110
SPINNER TC800L 110 CNC-svarv
CNC torna SPINNER TC800L 110
Get price & details
+34 679 …
Show phone
Details
About this seller
Specifications
Turning length
800 mm
Turning Ø
500 mm
Ø above the bed
800 mm
Length between centers
800 mm
Type of CNC
X-axis
360 mm
Z-axis
1580 mm
Max workpiece weight
800 kg
Spindle taper
Turning speed
5000 rpm
Tailstock
no
Bar feeder
no
-------------------
Length x width x height
5750.0
× 1980.0
× 2115.0
Weight
8500 kg
worked hours
hours under power
state
as-is, where-is
At local norms
---------
status
Datasheet
Spinner TC800L 110
Last availability date
25/04/2026
Show more
Automatic description (AI-Generated)
The SPINNER TC800L 110 is a 3-axis CNC horizontal turning machine manufactured in 2023, designed for precision turning tasks. It features a maximum turning diameter of 500 mm and a maximum swing diameter of 800 mm, with a turning length and distance between centers of 800 mm, extendable to 1580 mm in the L version. The machine supports a maximum workpiece weight of up to 800 kg, making it suitable for a range of medium to heavy-duty turning operations.
This model includes a spindle capable of reaching speeds up to 5000 rpm. The X-axis travel is 360 mm, and the Z-axis travel extends to 1580 mm, offering substantial machining range. The machine dimensions are 5750 mm in length, 1980 mm in width, and 2115 mm in height, with a total weight of 8500 kg.
Equipped with driven tools capable of up to 4000 rpm and power ratings between 2.2 kW (S1) and 5.5 kW (S3), the machine provides versatile tooling options. It features a turret with 12 tool stations using VDI50 tool holders, with optional configurations available. The main spindle has an A11 nose and a bar capacity of 110 mm, while the optional sub spindle has an A6 nose with a 52 mm bar capacity and a 210 mm chuck size.
Additional equipment includes a steady rest (note: the sensor bang-up requires replacement), tailstock with a 110 mm pinole diameter and MK4 taper, chip conveyor, and oil mist extraction system. The electrical supply is 3-phase 400 V with a rated current of 44 A and connected load of approximately 40 kVA.
The machine is housed within an enclosed cabinet featuring a control panel on the left side. It appears clean and well-maintained with no visible damage. Safety labels and warning stickers are present, and pipe or hose connections are attached to the machine's side. A wooden plank is resting on top of the enclosure.
This SPINNER TC800L 110 is suitable for users seeking a robust and precise CNC turning solution with comprehensive tooling and accessory options. For further information or to discuss specific requirements, please contact us.
The following description has been generated using artificial intelligence based on the product information available. It is provided for guidance only and may not reflect all specifications or conditions. Please contact us if you need precise or confirmed details.
Show more
Seller's description
This 3-axis SPINNER TC800L 110 was manufactured in 2023. The machine is fully functional and includes a steady rest, tailstock, chip conveyor, and oil mist extraction system. It operates on a 3-phase power supply at 400 V. If you are looking to get high-quality turning capabilities, consider the SPINNER TC800L 110 horizontal turning machine we have for sale. Contact us for further details.Status/condition
Machine powered on and still in operation
Fully functional; steady rest requires sensor bang-up replacement
Configuration and capacities
Turret without AgW (adjustable power supply)
Turret type: axial/radial
Number of tool stations: 12x VDI50 (option: 16x VDI40 or 12x BMT65)
Tool holder type: VDI50 (option: VDI40/BMT65)
Number of driven tools: 12 (option)
Driven tool speed: 4000 rpm
Driven tool power (S1/S3): 2.2 / 5.5 kW
Driven tool torque (S1/S3): 17.5 / 43 Nm (axial), 14 / 35 Nm (radial)
Maximum turning diameter: 500 mm
Maximum swing diameter: 800 mm
Turning length: 800 mm / 1580 mm (L version)
Distance between centers: 800 mm / 1580 mm
Maximum workpiece weight: 800 kg
Axes
Rapid traverse X/Z: 15 / 24 m/min
Spindles
Number of spindles: 3
Main spindle
Nose: A11
Bar capacity: 110 mm
Torque (100% / 40%): 175 / 235 Nm
Torque gear stage 2: 700 / 939 Nm
Sub spindle (option)
Nose: A6
Bar capacity: 52 mm
Chuck size: 210 mm
Power (S1/S6): 15 / 19 kW
Torque (S1/S6): 95 / 121 Nm
Tailstock (if equipped)
Pinole diameter: 110 mm
Taper: MK4
Stroke: 100 mm
Thrust force: 850 daN
Fluids and tanks
Coolant tank capacity: approx. 235 l (up to 270 l in L-version)
Hydraulic tank: approx. 31 l
Central lubrication tank: approx. 2–3 l
Electrical data
Electrical connection: 3-phase 400 V + N + PE
Frequency: 50/60 Hz (also stated as 50 Hz)
Rated current: 44 A
Fuse protection current: 50 A
Rated current protection: 63 A
Connected load: approx. 40 kVA (up to 50 kVA with 2 spindles)
Protection class: BA 3 (Chap. 3.4.5)
Network type: TN network with grounded neutral point
Recommended protection: without FI switch (recommended)
Additional equipment
Steady rest (note: sensor bang-up replacement needed)
Tailstock
Chip conveyor
Oil mist extraction system
Possibly chuck and tool holder (to be confirmed)
Counter Spindle: no
Driven Tools: yes
Machine Height: 2115 mm
Machine Length: 5750 mm
Machine Weight: 8500 kg
Machine Width: 1980 mm
Number of Axes: 5
Spindle Power: 29.5 kW
Spindle Speed: 5000 RPM
X-axis Travel: 360 mm
Y-axis Travel: 120 mm
Z-axis Travel: 1580 mm
Please note that this description may have been translated automatically. Contact us for further information. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase
