Weiler E30 cnc lathe

Weiler E30 cnc lathe
Top seller
View price
Request price
+34 679 …
Weiler
E30
1990
Germany
Lathes - CNC lathes
Ø above the bed
330 mm
Ø above transversing slide
160 mm
Type of CNC
Spindle taper
DIN 55027 Gr. 5
Spindle bore
42 mm
Turning speed
4500 rpm
Spindle motor power
11 kW
Tailstock
yes
Bar feeder
no
Length x width x height
1800.0 × 1200.0 × 1700.0
Weight
1300 kg
as-is, where-is
Datasheet
Weiler E30
12/08/2026
P250811099
This Weiler E30 CNC lathe, manufactured in 1990, is a robust and versatile horizontal turning machine designed for a wide range of turning operations. It features a spindle bore diameter of 42 mm and a maximum swing diameter over the bed of 330 mm, allowing it to handle medium-sized workpieces effectively. The lathe is powered by an 11 kW spindle motor capable of reaching turning speeds up to 4500 rpm, providing strong performance for precision machining tasks. The machine's dimensions are 1800 mm in length, 1200 mm in width, and 1700 mm in height, with a total weight of approximately 1300 kg. It includes a Multifix holder B, suitable for various tooling arrangements, and supports multiple thread cutting options, including metric, inch, module, and DP threads, with a maximum of 50 threads. Key components visible on the machine include a tailstock equipped with a handwheel and lever, a chuck mounted on the rotating spindle with an orange protective cover, and a tool post assembly inside the machine enclosure. The control panel, located on the top right of the machine, features multiple knobs and switches for operational control, alongside a prominently placed red emergency stop button for safety. The lathe bed and control panel housing show signs of paint chipping and wear, especially on the bed and around the control surfaces, indicating usage but no visible structural damage. A coolant hose with a nozzle is positioned near the chuck area to assist with machining cooling and chip removal. Safety labels and CE marking are present on the machine enclosure, which appears clean and intact. This Weiler E30 CNC lathe is suitable for detailed and versatile turning operations, offering a combination of power, precision, and a range of threading capabilities. For more detailed technical specifications or inquiries, please contact us. This Weiler E30 was manufactured in 1990. A robust horizontal turning machine featuring a spindle bore of 42mm and a swing diameter over bed of 330mm. It supports a wide range of thread cutting, from metric to DP thread, and includes a Multifix holder B. Ideal for detailed and versatile turning operations. Contact us for more information about this machine. Measurements width: 1200 mm
Measurements depth: 1800 mm
Measurements height: 1700 mm
Machine weight: 1300 kg
Spindle bore: 42 mm
Workpiece drm over bed: 330 mm
Multifix holder B mounted
Fixed steady rest (option) clamping range: 15-100 mm
Moving steady rest (option) clamping range: 10-85 mm
Collets ranging from 3-28 mm (increments of 0.5 mm)
Tailstock with an MK3 chuck
Drive power 100% / 60% ed: 9/11 kw
Max. Torque on the turning spindle: 180 nm
Total speed range: 1-4500 min⁻¹
Feed drive: three-phase ac feed drives
Feed range longitudinal: 0-20 mm/rev
Ellganggeschwindghell longitudinal/plan: 10/7. 5/5/3. 5 m/min
Quill diameter: 50 mm
Quill stroke: 110 mm
Inner taper of quill: mk 3
Swing diameter over facing slide: 160 mm
Bed width: 240 mm
Sliding movement of the facing slide: 180 mm
Bed slide guide length: 395 mm
Turning tool cross-section (height/width): 20 x 20 mm
Spindle head according to DIN 55027 Gr. 5
Spindle diameter in the front bearing: 70 mm
Inner taper of the main spindle: Mk 5
Workpiece
Metric thread range: 0.1 - 400 mm
Inch thread range: G/1" 1/4 - 56
Module thread range: 0.125 - 28 mm
DP thread range: 1-224 G/"
Number of threads max.: 50
Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase. 2019
