COMEV PICOTRE 500x4000 CNC lathe

Used COMEV PICOTRE 500x4000 parallel auto-feed turret lathe. Technical specifications include a manual mandrel diameter of 500 mm with a 3+3+3 thread, a kit for tooling, and a platform with 4 independent clamps diameter 800 mm. The machine is equipped with a rotating counterpoint CM6 for heavy loads, a mobile ring (serraggio diameter 50-300), a fixed ring (serraggio diameter 300-480), and a fixed ring with cushion (serraggio diameter 500-680). It also features a rear evacuator, a dust filter aspiration 3 vf, and a working capacity of 500 mm in height and 4000 mm in distance between points. The mandrel has a hole diameter of 130 mm and rotates at 1200 rpm, powered by a 39 Kw motor. The turret is of type VDI 50 with 8 tool ports. Specific properties include a maximum diameter allowed on the bed of 1000 mm and on the slide of 660 mm, a bed width of 550 mm, and an operating speed of 1200 rpm with a motor power of 39 Kw. The mandrel is attached with a 11 ASA. Please note that this description may have been translated or optimized with artificial intelligence (AI) automatically. The information of this classified ad are only indicative. We recommend to check the details with the seller before a purchase.
