Multi Spindle Drilling Machines DMG MORI CTX 310 ecoline
33750.00 €
Verhandlungsbasis
| Zustand | gebraucht |
|---|---|
| Hersteller | DMG |
| Baujahr | 2013 |
| Swing diameter over guide ways | 330 mm |
| Swing diameter over transverse guideway | 260 mm |
| Turning diameter | 200 mm |
| Transverse stroke | 182,5 mm |
| Longitudinal stroke | 455 mm |
| Clamping chuck diameter max. | 210 mm |
| Type of main drive | AC |
| Drive power (100% DC) | 11 kW |
| Drive power (40% DC) | 16,5 kW |
| Speed range | - 5000 rpm |
| Torque (100% DC) | 112 Nm |
| Spindle nose | Flat flange |
| Diametre of spindle nose | 140h5 mm |
| Spindle bore | 74 mm |
| Number of tool stations | 12 |
| Shank diametre according to DIN 69880 | 30 mm |
| Dimensions (L x W x H) | 4,47 x 2,01 x 1,75 m |
| Weight approx. | 3800 Kg |
| PROGRESSline | PROGRESSline Digital Cycle-time Graphic Rest Time Product Counter |
| 12 stations servo-tool turret reception VDI 30 | 12 stations tool turret (servo) reception VDI 30, make Sauter Note: option available only for machine in V1 version |
| Connection for oil mist extractor | Connection for oil mist extractor unit type AFS 600, dia. 150 mm (5,9 in), inclusive electrical connections only for AFS 600 |
| 8 free M-codes for Siemens 840D | 8 freely assignable M-Codes for SIEMENS 840D |
| Pre-setting package | Pre-setting Package: - tool pre-setting probe - chip conveyor instead of chip tank - 4 colour signal lamp |
| Tropical Package | Tropical Package: - Active Cooling Unit for Electrical Cabinet - Additional Ventilator for Control Panel Recommended from 35°C to max. 50°C environmental temperature. |
| Special equipment | Direct measuring system in the X-axis |
| 2013 | DMG MORI |
| 2012 | DMG MORI |
| 2014 | DMG MORI |
| 2004 | DMG MORI |
| 2009 | DMG MORI |
| 2011 | DMG MORI |
| 2015 | DMG MORI |
Beschreibung
Diese Feld muss ausgefüllt werden
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Model:CTX 310 ecoline
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:075151
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
---
[SRC:resale:169390149]
Diese Feld muss ausgefüllt werden
metal working machines / boring mills and machining centers / Multi Spindle Drilling Machines
Manufacturer:DMG MORI
Model:CTX 310 ecoline
Type of machine:Multi Spindle Drilling Machines
Seller-item-No.:075151
Please remit optionally
DMG MORI Used Machines GmbH
Ms Kerstin Bauer82538 GeretsriedGermany
---
[SRC:resale:169390149]
